MeoForce DF 4x30
Download product sheet: MeoForce DF 4x30
MeoForce DF 4x30 is the extension to the compact riflescope series, MeoForce DF 3x20 and MeoForce DF 5x40. Designed to be used mainly with assault rifles (AR) for its durability and reliability in extreme conditions. The red illuminated reticle allows using the system in various light conditions combined with red dot on the top for short distances (CQB) as well as for effective range of weapon system and with additional clip-on NV device during night time operations.
Features:
- MeoBright
- MeoDrop
- Waterproof
- Shock resistance
- Nitrogen Purged
- Night Vision Compatibility
Specifications:
| Magnification | 4x |
| Objective Lens Diameter (mm) | 30 |
| Exit Pupil Diameter (mm) | 7.5 |
| Eye Relief (mm) | 65 |
| Field of View (°) | 5.3 |
| Dioptric Correction (D) | -4/+4 |
| Focus Range (m) | 100 |
| Measured Integral Transmission Daylight (%) | 86 |
| Measured Integral Transmission Twilight (%) | 82 |
| Recoil Resistance (g) | 500 |
| Vertical Range (MOA) | min 100 |
| Vertical Step/100m (cm) | 2.5 |
| Horizontal Range (MOA) | min. 100 |
| Horizontal Step/100m (cm) | 2.5 |
| Reticle Illumination (Y/N) | Y |
| Reticle Brightness (cd/m2) | ≥40 |
| No. of Intensity Levels (Day/Night) | 8/4 |
| Power Supply (V) | 1,5 - 3,6 (1xAA) |
| Battery Lifetime* (hrs) | min. 300 |
| Automatic Shut Down (Y/N/hrs) | Y/8 |
| Operational Temperature Range (°C) | -40 / +60 |
| Storage Temperature Range (°C) | -45 / +71 |
| Moisture Resistance [+23/+40 °C] (%) | 80/98 |
| Water Resistance (m/hrs) | 2/2 |
| Dimensions with mounts, covers, eyepiece on max (L x H x W) (mm) | 167 x 67 x 64 |
| Weight with mounts, covers and battery (g) | 510 |
* - 1pc - LR6 1.5 V, size AA 2400 mAh and ambient temperature +20 °C, 11th level of intensity
